Features | PSHT030 | PSHT050 | PSHT075 | PSHT100 | PSHT150 |
Heating Capacity | 30W | 50W | 75W | 100W | 150 |
Power Supply | 100-250V AC DC | ||||
Maximum Current | 2A | 2A | 4A | 4A | 6A |
Heating element type | Resistance Heater | ||||
Overcurrent protection | Electronic thermal relay | ||||
Electrical connections | 3-Pole terminal block N-L-E | ||||
Protection Class IEC | CLASS II | ||||
Degree of Protection EN60529 | IP20 | ||||
Operating Temperature | -45 / +70 °C | ||||
Storage Temperature | -45 / +70 °C | ||||
Body | Anodized aluminum profile | ||||
Assembly | 35 mm DIN rail plug-in | ||||
Mounting Position | Vertical position for best efficiency | ||||
Dimensions HxWxD | 148x80x27 | 148x80x27 | 168x80x27 | 168x80x27 | 229x80x27 |
mm | mm | mm | mm | mm | |
Weight | 0.190 | 0.190 | 0.225 | 0.235 | 0.325 |
